Bansal Earthron · Strips & Terminals
GI Earthing Strip
50 × 3 mm
2m Length
50mm Pipe Size
Easy installation. Low maintenance. Precise size. Bansal Earthron's GI Earthing Strip is engineered for industrial earthing applications, connecting the electrode to the equipment being protected with a consistent, low-resistance galvanised path.
Supplied as a hot-dip galvanised steel strip in fixed inner-strip and pipe-size combinations, so runs bolt up cleanly on site without cutting or refitting. Suitable for all earthing and grounding systems.
Get A QuoteProduct Details
Usage / Application
Industrial
Inner Strip Size
50 × 3 mm
Length
2 Meter
Pipe Size
50 mm
Features
- Easy Installation
- Low Maintenance
- Precise Size
Specification
| Sr. No. | Pipe Size | Inner Strip Size | Length | Terminal Size | Terminal |
|---|---|---|---|---|---|
| 1 | 50 mm | 25 × 6 | 2 Mtr | 50 × 6 | G.I. |
| 2 | 50 mm | 25 × 3 (Copper) | 2 Mtr | 50 × 6 | Copper |
| 3 | 50 mm | 25 × 6 | 3 Mtr | 50 × 6 | G.I. |
| 4 | 50 mm | 25 × 3 (Copper) | 3 Mtr | 50 × 6 | Copper |
| 5 | 50 mm | 50 × 3 | 2 Mtr | 50 × 6 | G.I. |
| 6 | 50 mm | 50 × 3 (Copper) | 2 Mtr | 50 × 6 | Copper |
| 7 | 50 mm | 50 × 3 | 3 Mtr | 50 × 6 | G.I. |
| 8 | 50 mm | 25 × 3 (Copper) | 3 Mtr | 50 × 6 | Copper |
